NET200 is a USB/RS232 to RS232/RS485/RS422 serial converter with automatic setting of baud rate.
The serial input is galvanically isolated from both 12...24 VAC/DC power supply and from serial output.
The device is also powered up from USB , simplifying the wirings.
- Dimensions71x101 (front panel) x 28 mm - DIN Rail
- MaterialSelf-extinguishing polycarbonate
- WeightApprox. 120 g
- SealingBox and terminal blocks: IP20
- Operating conditionsTemperature 0-45 °C, humidity 35..95 uR% (non-condensing)
- CertificationsCE
| ORDERING CODES | NET200-1AD |
|---|---|
| Power supply | 12...24 VAC/DC ±15% 50/60 Hz or by USB port |
| Power consumption | 2 Watt/VA |
| Serial communication INPUT | 1x USB 2.0 B Type |
| Serial communication OUTPUT | 1x RS232 (1200..115200 Baud) galvanically isolated |
- Baudrate programmingAutomatic Selection up to 115000 Baud
- NET200-1ADUSB/RS232 to RS232/RS485/RS422 SERIAL CONVERTER
