EE210 is the ideal transmitter for accurate measurement of relative humidity and temperature in critical climate control applications.
With the electronics encapsulated in the probe and the sensing element protected with patented coating, the EE210 can be used even in harsh environmental conditions.
- DimensionsBox 101 x 81 mm - Stem 89x12 mm
- SealingIP65
- Operating conditions-40°C ... +60°C
- CertificationsCE, UKCA
| ORDERING CODES | 2000.50.033 / 034 / 037 / 038 / 040 / 042 |
|---|---|
| Power Supply | 15..35 V DC - 15.28 V AC |
|
Consumption |
20 mA |
|
Working range | 0..100 % |
|
Accuracy @ 20°C |
+/- 2% RH (0...90% RH) / +/-3% RH (90..100% RH) |
|
Response time @ 25°C |
< 15 seconds |
|
Analogue output humidity |
4..20 mA |
|
Operating temperature |
-40..60 °C |
|
Accuracy @ 0°C |
± 0,15 °C |
|
Analogue output Temperature |
4..20 mA |
|
Sensor Cap |
Membrane |
|
Mounting |
Wall |
- 2000.50.033HUMID+TEMP. SENS. EE210-M1T1A6F2SBL-20SBH80 Out 2 x 4...20mA - Wall mounting
- 2000.50.034HUMID+TEMP. SENS. EE210HT6XPBXBUWTX024M Out 2 x 4...20mA - In duct mounting
- 2000.50.037HUMID+TEMP. SENS. EE210-HT3xPBFxB/UwTx024 Out 2 x 0...10V - In duct mounting
- 2000.50.038HUMID+TEMP. SENS. EE210 Out 2 x 0...10 V Wall mounting 200mm
- 2000.50.040HUMID+TEMP. SENS. EE210HT6XPBXCUWTX005M Out 2 x 4...20mA - In duct mounting
- 2000.50.042HUMID+TEMP. SENS. EE210HT6XPADBUW005TX004M Out 2 x 4...20mA - Wall mounting + Disp.
